Exfo EtherCHK1-10G 10GE Ethernet Tester

Exfo EtherCHK1-10G 10GE Ethernet Tester

The EXFO EtherCHK1-10G 10GE Ethernet Tester is a portable instrument for installing, verifying, and troubleshooting Ethernet services. It tests connections from 10 megabits per second to 10 gigabits per second, helping technicians confirm that a network delivers its expected performance.

The tester supports copper Ethernet through an RJ45 connection at 10/100/1000 Mbps and optical Ethernet through SFP/SFP+ interfaces up to 10 Gbps. This allows technicians to check different network connections using suitable transceivers.

Its main testing tools include RFC 2544 and EtherSAM, EXFO’s implementation of the ITU-T Y.1564 service activation methodology. These evaluate performance measures such as throughput, delay, frame loss, and packet jitter, helping verify that services meet agreed requirements.

The EtherCHK1-10G also generates and monitors test traffic and performs bit-error-rate testing with EtherBERT. Remote discovery and Smart Loopback help a technician test an entire connection using compatible equipment at the opposite end.

An eight-inch color touchscreen provides controls, results, and pass/fail indicators. The tester can save configurations and generate PDF or HTML reports for customers and maintenance records.

Features:

• Ethernet testing at 10/100/1000 Mbps and 10 Gbps
• RJ45 copper interface supporting up to 1 Gbps
• SFP/SFP+ optical interfaces supporting up to 10 Gbps
• EtherSAM (ITU-T Y.1564) service activation testing
• RFC 2544 throughput, frame loss, and latency testing
• EtherBERT bit-error-rate testing
• Multistream traffic generation and monitoring
• Smart Loopback and remote tester discovery
• Dual-port testing capability
• Copper Ethernet cable diagnostics
• VLAN and Q-in-Q testing
• Configurable pass/fail thresholds
• 8-inch color touchscreen
• 64 GB internal storage and microSD expansion
• PDF and HTML test reports
• USB connectivity
• Rechargeable lithium-ion battery
