Exfo EtherCHK-1G 1GE Ethernet Tester

Exfo EtherCHK-1G 1GE Ethernet Tester

The EXFO EtherCHK-1G is a portable Ethernet tester used to install, verify, and troubleshoot network services operating at speeds up to 1 gigabit per second. It supports 10/100/1000BASE-T copper Ethernet and 1 Gigabit optical Ethernet, making it useful for checking both copper and fiber connections.

The tester generates network traffic and measures how effectively a connection carries it. By checking throughput, frame loss, latency, and packet delay variation, technicians can investigate slow connections and confirm whether a service meets its expected performance requirements.

Its EtherSAM test suite follows the ITU-T Y.1564 service activation methodology to evaluate service configuration and performance. It also supports RFC 2544 testing, providing standardized measurements that help technicians verify Ethernet services before handing them over to customers.

Intelligent network discovery and Smart Loopback help technicians establish tests with compatible remote equipment. These functions simplify end-to-end testing, while EtherBERT checks transmission errors and multi-stream traffic generation evaluates how a connection handles different traffic flows.

Designed for field use, the EtherCHK-1G combines a portable platform with an eight-inch touchscreen, stored test configurations, and report generation. It helps network teams document results, troubleshoot service problems, and confirm successful installations.

Features:

• Copper Ethernet testing: Supports 10/100/1000BASE-T through RJ45.
• Optical Ethernet testing: Supports 1 Gigabit Ethernet using compatible optical transceivers.
• EtherSAM testing: ITU-T Y.1564 service configuration and performance validation.
• RFC 2544 testing: Measures throughput, frame loss, latency, and back-to-back performance.
• EtherBERT: Checks bit-error performance.
• Multistream traffic generation: Tests multiple Ethernet/IP traffic flows.
• Traffic monitoring: Measures throughput, frame loss, packet jitter, latency, and out-of-sequence frames.
• Intelligent network discovery: Finds compatible remote EXFO testers.
• Smart Loopback: Returns test traffic for end-to-end testing.
• Cable testing: Helps troubleshoot copper connections.
• Eight-inch multitouch display: Provides a large interface for setup and results.
• Report generation: Documents test results.
• Save/recall configurations: Reuses established test settings.
• 64 GB onboard storage: Expandable through microSD.
• USB connectivity: Supports external devices and file transfer.

Specifications:
