Viavi INX 660 Probe Microscope

Viavi INX 660 Probe Microscope

The VIAVI INX 660 Probe Microscope is a handheld inspection tool for examining the end faces of fiber-optic connectors. It helps technicians spot contamination, scratches, and other conditions that could affect a fiber connection. It is designed for field work where connectors need to be checked before they are joined or returned to service.

For single-fiber connectors, the INX 660 automates the inspection process: it sets up the test, focuses and captures an image, analyzes the connector end face, and saves the result. This gives technicians a repeatable way to assess connector condition without manually adjusting each step. It also supports semi-automated inspection of multifiber connectors.

The microscope uses interchangeable inspection tips for different connector types. Its AutoID tips identify the tip in use, helping the instrument apply the appropriate setup. A built-in color touchscreen lets the technician view images and results directly on the probe while working at a panel, cabinet, or other fiber access point.

Inspection results can be stored for documentation and transferred through USB-C or wireless connections for reporting. The INX 660 is useful during fiber installation, maintenance, and troubleshooting because it helps crews identify connectors that need cleaning or further attention before making a connection. It inspects connector end faces; it does not clean them.

Features

• Automated single-fiber inspection: Sets up the test, focuses, captures the image, analyzes the connector end face, and saves the result.
• Semi-automated multifiber inspection: Supports inspection of multifiber connectors with compatible tips.
• AutoID inspection tips: Recognizes the installed tip to reduce manual setup.
• Built-in color touchscreen: Displays live connector images and inspection results on the probe.
• Fast analysis: VIAVI specifies autofocus and analysis in 4 seconds or less for a single fiber.
• Result storage: Holds up to 10,000 single-fiber results or 1,500 multifiber results.
• USB-C and wireless connectivity: Transfers results to other devices for documentation and reporting.
• Field-ready design: Rechargeable, serviceable battery and a compact handheld body.
