3M Dynatel 2573 X Cable & Pipe Locator
Condition: Refurbished
Warranty: 1 YEAR WARRANTY
Shipping: USA & Worldwide
- 3M Dynatel 2573 X Cable Pipe Locator (BC# -L/T*)
- 3M Dynatel 2573 Cable Locator Transmitter w/ Strap (BC# -L/T*)
- 3M Dual Clip Coupler Cable
- 3M Coupler Cable
- 3M 3001 Dyna Coupler
- Ground Stake
3M Dynatel 2573 X Cable Pipe Locator
3M Dynatel Locators 2550X/2573X Series integrates locating, and fault finding technology for the field professional. It features a lightweight design, large display with easy-to use interface, enhanced connectivity, internal GPS module, and includes Li-Ion battery with built-in charger.
3M Dynatel 2550X/2573X Locator is capable of locating cable and pipe. This locator has simplified integrated interfaces with precision locating capabilities, six active frequencies for direct connect and trace view mapping display mode. A GPS communication system is incorporated into this Dynatel locator to provide GIS mapping. The Dynatel locator operates at a temperature of 4 to 122 °F ( 20 to 50 °C). It includes a 3W or 12W transmitter that has four induction frequencies with maximum allowed output power and all frequency mode in direct connect (four simultaneously).
Specifications:
| Physical Specifications | |
| Size | |
| Transmitter | 6.75" H x 11.25" W x 7.75" D (17.2 cm x 28.6 cm x 19.7 cm) |
| Receiver | 25.5" H x 3.75" W x 10.75" D (64.8 cm x 9.5 cm x 27.3 cm) |
| Weight | |
| Transmitter | 5.2 lbs. (2.4 kg) |
| Receiver | 4.1 lbs. (1.8 kg) |
| Shipping | 14.3 lbs. (6.5 kg) |
| Environmental Specifications | |
| Operating temperature | 4° to 122°F (-20° to 50°C) |
| Storage temperature | -40° to 158°F (-40° to 70°C) |
| Electrical Specifications | |
| Receiver | |
| Frequencies | |
| Cable/Pipe Depth Accuracy | ±2% ± 2 in. (5 cm) for 0–60 in. (1.5 m) ±6% ± 2 in. (5 cm) for 60–120 in. (1.5–3.0 m) ±10% ± 2 in. (5 cm) for 120–180 in. (3.0 m–4.5 m) |
| Cable/Pipe Depth Range | 0–360 in. (0–914 cm) |
| Locate Modes | Trace View (Compares Peak and Null While Locating), Directional Peak, Directional Null (Provides 360° locate), Special Peak, Dual Peak |
| Frequencies for 3M™ Dynatel™ Locators 2573X Series |
Active: 577 Hz,1 kHz, 8 kHz, 33 kHz, 82 kHz, 200 kHz Tone: 577 Hz and 200 kHz pulsing at 8 Hz |
| Passive Frequencies | 15 – 30 kHz (LF), 31.5 kHz (CATV) |
| User Defined Frequencies | Four (50 Hz to 999 Hz) |
| Sonde Frequencies | 512 Hz, 640 Hz, 8 kHz, 33 kHz |
| Power | Six alkaline “AA” (LR6) cells |
| Typical battery life | 50 hours |
